4 Series Mobile Gas Generator Set J420

J420
Based on the improvement of the 3 series and 6 series product designs, the advanced 800-1500kW level 4 series gas generator sets stand out with their high energy density and excellent efficiency. Optimized control and monitoring ensure easy maintenance and the highest availability and reliability.
Environmental protection, biogas, petrochemical, agriculture, landfill gas, combined heat and power, generator set, combined heat and power system, natural gas, fuel, greenhouse.

Consult

Features
Technical Indicators
Overall Dimension


Structure: 70° Cylinder diameter (mm): 145 Stroke (mm): 185 Displacement/cylinder (1): 3.06 Speed (rpm): 1,800/1,200 (60 Hz) 1,500 (50 Hz). Average piston speed (m/s): 7.4 (1200rpm) 9.3 (1500rpm). Scope of supply: generator set, combined heat and power system, container generator set/combined heat and power system. Available fuel gas: natural gas, associated gas, biogas, landfill gas, sewage gas, special fuel gas (such as coal bed gas, coke oven gas, wood gas, high temperature cracking gas, etc.). Generator model: J420 Number of cylinders: 20 Total displacement (1): 61.1
